EINHELL TC-SP 204 Operating Instructions

GB
- 21 -
•
Plane
•
Push stick
•
Slide block (2x)
•
Open-ended wrench
•
Hexagon wrench, small
•
Hexagon wrench, medium
•
Hexagon wrench, large
•
Rubber foot (4x)
•
Assembly material
•
Original operating instructions
•
Safety information
3. Proper use
The surfacing and thicknessing plane is designed
for the surfacing and thicknessing of all types of
whole pieces of square, rectangular or chamfered
converted timber.
The machine is to be used only for its
prescribed purpose.
Even when the machine is used as prescribed
it is still impossible to eliminate certain residual
risk factors. There is a risk of the following injuries
in connection with the required operation of the
machine.
•
Fingers or hands coming into contact with the
knife block in areas which are out of view.
•
Workpieces may kick back if the machine is
used incorrectly.
•
Damage to hearing and eye injuries plus
injuries to fingers and hands if the required
protective equipment is not used.
•
Harmful emissions when used in enclosed
areas without a suitable extractor system.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Technical data
AC motor: ................................220-240 V ~ 50 Hz
Power P: .................................................. 1500 W
Protection type: ............................................IPX0
Max. workpiece width: ............................ 204 mm
Max. workpiece height at
thickness opening: ................................. 120 mm
Surfacing plane table: ...................357 x 210 mm
Thicknessing table: ....................... 270 x 210 mm
Thicknessing feeding speed: ..................6 m/min
Idle speed of motor n0: ......................... 9000 rpm
Idle speed of planing knives: ................ 9000 rpm
Max. planing cross-cutting depth: ............... 3 mm
Max. thicknessing cross-cutting depth: ...... 2 mm
Max. angle of the parallel stop: .......................45°
Sawdust extractor: ..............................Ø 100 mm
Weight: ........................................ approx. 26.5 kg
Danger!
Sound and vibration
Sound and vibration values were measured in
accordance with EN 61029.
L
pA
sound pressure level ..................... 92,9 dB(A)
K
pA
uncertainty ........................................ 3 dB(A)
L
WA
sound power level ..................... 105,9 dB(A)
K
WA
uncertainty ........................................ 3 dB(A)
Wear ear-muff s.
The impact of noise can cause damage to hea-
ring.
Warning!
The speci ed vibration value was established in
accordance with a standardized testing method. It
may change according to how the electric equip-
ment is used and may exceed the speci ed value
in exceptional circumstances.
The speci ed vibration value can be used to
compare the equipment with other electric power
tools.
The speci ed vibration value can be used for initi-
al assessment of a harmful eff ect.
Anl_TC_SP_204_SPK9.indb 21 19.06.2023 08:46:42

EINHELL TC-SP 204 Specifications

General

Power	1500 W
Feed rate	6 m/min
Idle speed	9000 RPM
Dust extraction	Yes
AC input voltage	230-240 V
AC input frequency	50 Hz
Planning width (max)	204 mm
Dust adapter diameter	100 mm
Thickness opening (max)	120 mm
Parallel guide tilt angle (max)	45 °
Surface planing material removal (max)	3 mm
Thickness planing material removal (max)	2 mm

Weight and Dimensions

Weight	27200 g
Package depth	850 mm
Package width	425 mm
Package height	465 mm
Package weight	31150 g
Feed table dimensions (W x D)	370 x 210 mm
Thicknessing table dimensions (W x D)	270 x 210 mm
