EINHELL TC-SP 204 Operating Instructions

GB
- 25 -
10. Cleaning, maintenance and
ordering of spare parts
Danger!
Pull out the power plug before performing any
maintenance, cleaning and adjusting work
10.1 Cleaning
•
Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible. Wipe the equipment with a clean
cloth or blow it with compressed air at low
pressure.
•
We recommend that you clean the device
immediately each time you have finished
using it.
•
Clean the equipment regularly with a moist
cloth and some soft soap. Do not use
cleaning agents or solvents; these could at-
tack the plastic parts of the equipment. Ensu-
re that no water can seep into the device. The
ingress of water into an electric tool increases
the risk of an electric shock.
10.2 Maintenance (Figure 1/15)
Important: Pull the mains plug before starting
and maintenance work.
10.2.1 Machine
Lubricate the following parts periodically after
around 10 hours of service:
•
Bearings for the feed/discharge rollers (f) and
anti-kick claws (24)
•
Bearings on the belt roller and pulley
•
Grub screws to adjust the height of the thick-
nessing table (20)
Use only dry lubricant.
The feed table (13), planing table (14), thicknes-
sing table, feed/discharge rollers and anti-kick
claws (24) must be kept free of resin at all times.
Soiled feed/discharge rollers or anti-kick claws
(24) must be cleaned without delay.
To prevent the motor overheating, the dust that
accumulates in the ventilation openings must be
removed at regular intervals.
Improve the smooth running of the tables by ap-
plying lubricant at regular intervals.
10.2.2 Cutting tool
Resin must be cleaned off the knife (21), latch
(22) and knife block (23) at regular intervals.
Clean these components with an appropriate
resin remover.
10.3 Ordering replacement parts:
Please quote the following data when ordering
replacement parts:
•
Type of machine
•
Article number of the machine
•
Identification number of the machine
•
Replacement part number of the part required
For our latest prices and information please go to
www.Einhell-Service.com
11. Disposal and recycling
The equipment is supplied in packaging to pre-
vent it from being damaged in transit. The raw
materials in this packaging can be reused or
recycled. The equipment and its accessories are
made of various types of material, such as metal
and plastic. Never place defective equipment in
your household refuse. The equipment should
be taken to a suitable collection center for proper
disposal. If you do not know the whereabouts of
such a collection point, you should ask in your
local council offi ces.
12. Storage
Store the equipment and accessories out of
children’s reach in a dark and dry place at above
freezing temperature. The ideal storage tempe-
rature is between 5 and 30 °C. Store the electric
tool in its original packaging.
Anl_TC_SP_204_SPK9.indb 25 19.06.2023 08:46:43

EINHELL TC-SP 204 Specifications

General

Power	1500 W
Feed rate	6 m/min
Idle speed	9000 RPM
Dust extraction	Yes
AC input voltage	230-240 V
AC input frequency	50 Hz
Planning width (max)	204 mm
Dust adapter diameter	100 mm
Thickness opening (max)	120 mm
Parallel guide tilt angle (max)	45 °
Surface planing material removal (max)	3 mm
Thickness planing material removal (max)	2 mm

Weight and Dimensions

Weight	27200 g
Package depth	850 mm
Package width	425 mm
Package height	465 mm
Package weight	31150 g
Feed table dimensions (W x D)	370 x 210 mm
Thicknessing table dimensions (W x D)	270 x 210 mm
