EK-Quantum Vector RTX 3080/3090 Backplate - Apply Thermal Pads to Backplate

- 7 -
STEP 3
Once cut to size, thermal pads should be placed on the backplate,
as illustrated below.
STEP 3
RTX™ 3080
RTX™ 3090
Thermal Pad G 1.5 mm
Thermal Pad
G 2.0mm
Thermal Pad G 1.5 mm
Thermal Pad
G 1.0 mm
Thermal Pad
G 2.0 mm
