6
CP micro – from page 7 on
CP integra – from page 13 on
FS IN into ekey dLine ngerprint scanner – from page 18 on
Disconnect the devices from the power supply before you start removing them.
It may be that the ekey dLine control unit including the adapter cable does not have enough space.
With wooden doors, but also behind the cable transfer or the lock, the space is usually very limited.
First check whether the new parts have space before continuing the conversion.
Carry out the test mode as soon as the devices have been replaced and before they are installed in the door:
Restore the power supply. Wait until the top-left LED segment on the ekey dLine ngerprint scanner ashes blue.
Place any nger within 10 minutes on the sensor. The motorized lock switches.
Then disconnect the power supply again and complete the installation of the ekey dLine ngerprint scanner and
control unit.
How to replace the control panel
How to replace the nger scanner integra
Important information for the conversion
