Maintenance
User Manual Biosen C_line Clinic / GP+
46
46
Pull the tube away from the
sample cannula and loosen the
fastening screws.
Figure 28 - loosen screws
Take off the cover plate of the
pivot arm and pull out the sample
cannula upwards.
Figure 29 - pull out sample cannula
Turn the exchanger at the tube
connection until it is at right angles
to the pivot and then pull it out
forwards.
Figure 30- pull out exchanger
Pull the exchanger out of the tube
and put on a new exchanger.
Push the tube as far as it will go.
Figure 31 - change exchanger
Construction is in the opposite order.
Loosen screws
Sample
cannula
Exchanger
