1 DESCRIPTION
Astro digital timer TM-AS is used for automatic control of lighting
(or other electrical equipment) using two independent groups of
contacts with no light sensors with controlled switching by sunset
and sunrise time based on location coordinates.
The product corresponds to GOST IEC 60947-1-2014,
GOST IEC 60947-5-1-2014.
2 TECHNICAL DATA
Table 1.
Parameter Value
Артиул tm-as tm-as-1
Rated supply voltage (Un), V
AC/DC
24-264
230 АС
Rated frequency, Hz 50/60
Insulation voltage, Ui, V 250
Maximum switching current
of contacts, А
at cosφ = 1 16
at cosφ = 0,7 10
Maximum number of programms 80 52
Utilization category AC1
Type and number of contacts 2 C/O 1 C/O
Maximum switching power
4000 ВА/АС1;
384 Вт/DC
Error of time counting, s/day, not more ±1
Battery life, years, not less 10
Power consumption, VA, max. 2 1
Electrical endurance, cycles 100 000
Mechanical endurance, cycles 1 000 000
Maximum cross-section of connected wires,
mm
2
4
Tightening torque, N·m 0,5
