4
There are setup buttons for current time and timer programming,
LED illuminated display on the front panel of the timer under
transparent cover with possible sealing.
Display indicators:
– Weekdays:
Monday... sunday
C1 – Channel №1 setting up
C2 – Channel №2 setting up
– Contact position
– Automatic mode
– Manual mode
– Holiday mode
– Winter time
– Summer time
– Program conguration
– Random mode
– Sunrise
– Sunset
Figure 1. Front panel.
