4
The product shall be operated under the following ambient
conditions:
- Non-explosive;
- No aggressive gases and steam in concentration that can destroy
materials and insulation;
- No current conducting dust and steams;
- No direct ultrapholic rays impact.
The product housing is made of АВС-plastics that doesn’t sustain
combustion.
Number of
channel
Week
days
Operating
mode and
ettings
Current
time
MENUOK
Button
for c
onfirmation
of selection
Select buttons
Current
day
Button
f
or entry the
main menu
Fig. 1 - Front panel
