Model
EB12E
Load capacity
(lb)
2640
Load capacity on Max. height(kg)
(lb)
1540
The max. lifting height
(in)
119.4
Load center distance
(in)
24
Fork length
(in)
45
Single fork width
(in)
4
Overall fork width
(in)
8.3-33.5
Lowered fork height
(in)
2.35
Fixed leg length
(in)
36.5
Fixed leg width, single (Including the
front double frame)
(in)
5
Inside width between fixed legs
(in)
35.4-59
Turning radius
(in)
52.6
Front wheel size, number
φ3.1×2.7
、
4
Rear wheel size, number
φ8.3×2.7
、
1
Balance wheel size, number
φ6×2.3
、
1
Overall length
(in)
71
Max Overall width
(in)
61
Extended mast height
(in)
135
Lowered mast height
(in)
82
Battery voltage (dimensions)
(in)
2×12V/100AH
（
10/6.6/8.5
）
The charger
V/A
24V/15A
Lifting Motor
V/Kw
2.2kw. Lift speed,
laden/unladen:92/136mm/s
Lowering speed:
laden/unladen:112/98mm/s
Driving Motor
0.75kw.Driving speed:
laden/unladen:4.0/4.2km/h
Service Weight
(lb)
1023
