3
c. Check and refill hydraulic oil
According to the temperature, we recommend the type of hydraulic oil as following:
Temperature –5℃~ 25℃ >25℃
Model
HVLP 32，
DIN 51524
HLP 46，
DIN 51524
Viscosity 28.8-35.2 41.4 - 47
Oil volume 14~15L
Wasted material such as waste oil, waste battery or other material must be processed and recycled in accordance
with the national regulation. And if necessary, they need to be handed over to recycle companies to recycle.
The oil level should not be lower than the minimum amount of oil required when the vehicle start out.
If necessary, please add the oil to the filling points.
contact
Bearing shaft
