33
APP/Wi-Fi Control (Cont.) INSTALLIING INDOOR CAMERA
1. Locate area you wish to install camera and drill 2 x holes
(17 mm distance from hole to hole). Drill hole thickness
must match same thickness as the plugs (B) provided.
2. Lightly hammer in the plugs (B) until flat with wall, then
place the mount (A) over the holes of plugs and fasten
screws (C) into place.
3. Then use the mount screw (D) fasten to the bottom of
the camera. (Make sure to screw all the way in).
4. Now slide the camera with mount screw (D) into
the mount (A). It will slide in perfect, though if a bit loose
once camera has been inserted properly into the mount (A).
Twist the base of camera to tighten mount screw (D) further.
A B
C
D
