EKO MS-802 User Manual

EKO INSTRUMENTS CO., LTD. - Pyranometers MS-802/802F/402/402F/602 - Instruction Manual Ver.13
Pg. 10
5. Getting Started
5-1. Parts Name and Descriptions
Each part name and its main function is described below.
Figure 5-1. Pyranometer Parts Name
*Spirit level is not shown on the drawings for MS-802/402 due to its position on the cross-section drawings.
Parts Name
A. Inner Glass Dome
B. Outer Glass Dome
C. Sensor
D. Body
E. Sun Screen (Cover)
F. Leveling Screw
G. Drying Cartridge (Silica Gel)
H. Cable, Connector
I. Spirit Level(*)
J. Ventilation Fan
K. Ventilation Unit Body
E
K
J
F
Table 5-1. Parts Name
MS-802/402
MS-802F/402F
MS-602
C
B
D
F
H
I
G
.
A B
C
E
D
F
G
H

EKO MS-802 Specifications

General

Brand	EKO
Model	MS-802
Category	Measuring Instruments
Language	English
