EKO MS-802 User Manual

EKO INSTRUMENTS CO., LTD. - Pyranometers MS-802/802F/402/402F/602 - Instruction Manual Ver.13
Pg. 21
Table 7-2. Other Specification
Characteristics
MS-802 / MS-802F
MS-402 / MS-402F
MS-602
Field of View
2π (sr)
Wavelength range
285 to 3000 nm
Operating Temperature
(Accuracy guarantee range)
-40 to +80℃ (-10 to +50℃)
Operating Temp. with
Ventilation
(Accuracy guarantee range)
-40 to +50℃ (-10 to +50℃)
-
Ingress Protection of
Pyranometer
(IP Code)
IP67(IEC60529, JIS C0920)
* Maximum Operation
Irradiance
4000 W/㎡
2000 W/㎡
Weight (with ventilation)
1.4kg (3kg)
230g
Paint
Munsell Color: N-9.5 White, Baked
White Anodized
Sensitivity
Approx. 7.00μV/W･m
-2
Impedance
Approx. 500Ω
20 to 140Ω
Output Cable (outer diameter)
0.5mm
2
x 2 pins (φ6.7mm)
0.3mm
2
x 2 pins
(φ4.8mm)
Output Cable Terminal
Pin-Terminal (1.25-11S)
Pin-Terminal
(1.25-11S)
**Ventilation Supply
Power
AC
120V, 220V, 240V,
16W @ 50Hz/15W @ 60Hz
-
DC
12V or 24V
-
Power Supply Cable (outer
diameter)
0.75mm
2
x 3 pins (φ6.8mm)
-
DC Power Supply Cable
Terminal
Ring Terminal (1.25-4)
-
* The operational maximum irradiance is defined as the irradiance level beyond which damage may occur to
the sensor.
**There are 2 different types of supply powers for the ventilation; please specify when purchasing.

EKO MS-802 Specifications

General

Brand	EKO
Model	MS-802
Category	Measuring Instruments
Language	English
