Technical Specification:
- Dimensions (L x H x W): 91 x 91 x 22 mm
- D-RGB cable length: 500 mm
- D-RGB LED count: 1
- D-RGB connector standard 3-pin (+5V, Data, Blocked, Ground)
Position EAN Description Quantity
1
100668 COLDPLATE - Copper
1
100669 COLDPLATE - Nickel
2
100830 VELOCITY FRAME - Black
1100831 VELOCITY FRAME - Nickel
100832 VELOCITY FRAME - White
3 8207 SCREW M4 x 14 DIN7991 4
4 100663 EK-BADGE 1
5 100575 INTEL MOUNTING PLATE 1
6
101691 TOP PLATE - Strike Black Nickel
1101692 TOP PLATE - Strike Matte Black
100528 TOP PLATE - Full Nickel
7 100629 JE T PL ATE 1
8 100728 SEALING GASKET 1
9 102213 LED D-RGB PANEL 1
10
101693 STRIKE COVER - Black Elox
1101694 STRIKE COVER - Natural Elox
102500 HONOR COVER - Stars & Stripes
2
9
4
1
7
8
10
6
3
5
