ELAC DCB41 - Turntable Connection Guide

Audio Out
R
L
Ground
Optional
Note: Some turntables have built in phono pre-amplifiers that can be disabled. Ensure the turntable pre-amplifier
is set to OFF and DCB41 is set to ON.
If you choose to use the turntable’s Phono pre-amplifier, then ensure its switch is set to ON postion and DCB41 is
set to OFF.
The Ground connection is optional. It is recommended to be used as it can lower residual noise.
CONNECTIONS - TURNTABLE
ELAC DEBUT ConneX DCB41 | www.elac.com | Page 5




'()*+,'(
+-.++.
-/
0



ON/OFF
Set to ON if plugging into a turntable
XBASS
XBass is a propietary circuit to boost low frequency performace.
Turn ON/OFF
Press and hold XBass button on remote for 2 seconds :
LED display will blink once for OFF
LED display will blink twice of ON
When ON - pressing XBass will cycle XBass setting.
If connecting a subwoofer, XBass can be turned OFF completely.
XBass
