ELAN HOME SYSTEMS
INSTALLATION MANUAL
© ELAN Home Systems 2003 • All rights reserved. 06/2003
8
M SERIES INSTALLATION GUIDELINES
5.25" Model Cutout Dimensions Dimensions w/ Frame Total Depth
Depth
ME525D 6-13/16" (173mm) diameter 8" (203mm) diameter 4-1/8" (104mm)
ME525C 6-13/16" (173mm) diameter 8" (203mm) diameter 4-1/8" (104mm)
ME525W 6-1/8" x 10-1/4" (156x260mm) 7-3/8" x 11-9/16" (187x294mm) 3-3/4" (94mm)
MM525C 6-13/15" (173mm) diameter 8" (203mm) diameter 4-1/4" (107mm)
MM525W 6-1/8" x 10-1/4" (156x260mm) 7-3/8" x 11-9/16" (187x294mm) 3-3/4" (94mm)
MP525W 6-1/8" x 10-1/4" (156x260mm) 7-3/8" x 11-9/16" (187x294mm) 3-3/4" (94mm)
6.50" Model Cutout Dimensions Dimensions w/ Frame Total Depth
MC650C 8-1/16" (205mm) diameter 9-1/4" (235mm) diameter 3-5/8" (92mm)
MC650W 7-1/8" x 12-1/4" (181 x 311mm) 8-1/4" x 13-1/2" (210 x 343mm) 3-5/16" (83mm)
ME650C 8-1/16" (205mm) diameter 9-1/4" (235mm) diameter 4-1/4" (107mm)
ME650W 7-1/8" x 12-1/4" (181 x 311mm) 8-1/4" x 13-1/2" (210 x 343mm) 3-3/4" (94mm)
MM650C 8-1/16" (205mm) diameter 9-1/4" (235mm) diameter 4-1/2 (111.5mm)
MM650W 7-1/8" x 12-1/4" (181 x 311mm) 8-1/4" x 13-1/2" (210 x 343mm) 3-3/4" (94mm)
MM650D 8-1/16" (205mm) diameter 9-1/4" (235mm) diameter 4-1/2" (111.5mm)
MP650 C 8-1/16" (205mm) diameter 9-1/4" (235mm) diameter 4-13/16" (122mm)
MP650 W 7-1/8" x 12-1/4" (181 x 311mm) 8-1/4" x 13-1/2" (210 x 343mm) 3-13/16" (96mm)
8" Model Cutout Dimensions Dimensions w/ Frame Total Depth
ME800C 9-3/4" (248mm) diameter 11" (278mm) diameter 4-13/16" (122mm)
MM800C 9-3/4" (248mm) diameter 11" (278mm) diameter 4-13/16" (122mm)
MM800W 8-5/8" x 15-3/16" (219 x 386mm) 9-7/8" x 16-1/2" (251 x 419mm) 4" (102mm)
MP800C 9-3/4" (248mm) diameter 11" (278mm) diameter 5" (127mm)
MP800W 8-5/8" x 15-3/16" (219 x 386mm) 9-7/8" x 16-1/2" (251 x 419mm) 4" (101mm)
MP800S 8-5/8" x 15-3/16" (219 x 386mm) 9-7/8" x 16-1/2" (251 x 419mm) 4" (101mm)
MP800D 9-3/4" (248mm) diameter 11" (278mm) diameter 5-1/12" (139mm)
