© ELAN Home Systems 2003 • All rights reserved. 06/2003
ELAN HOME SYSTEMS
INSTALLATION MANUAL
7
M SERIES SPECIFICATIONS AND DRIVER COMPONENTS
The ELAN M Series In-Wall/In-Ceiling Loudspeaker line is constructed using the finest
materials available to provide a lifetime of listening enjoyment.
Specs MC (Level 1) ME (Level 2) MM (Level 3) MP (Level 4)
Tweeter PEI Silk Silk Aluminum and
Material Magnesium
Composite
Woofer Cone Polypropylene Mineral Filled Injection Molded Woven Glass
Polypropylene Mica Fiber
Woofer Inverted Butyl Inverted Butyl Inverted Butyl Inverted Butyl
Surround
Woofer Stamped Stamped Stamped Glass Fiber
Basket Composite
Crossover 6dB/octave 6dB/octave 12dB/octave Linkwitz/Riley
Response
Crossover None None Treble Treble/Bass
Switches
Interconnect 20AWG 20AWG 18AWG 16AWG
Wire
Input Spring Spring Gold-Plated Gold-Plated
Connectors Terminals Terminals Push Terminals Push Terminals
Hardware Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Nominal 8 Ohms 8 Ohms 8 Ohms 8 Ohms
Impedance
Sensitivity 87dB 87-90dB 88-91dB 89-93dB
Range (1W/1Meter) (1W/1Meter) (1W/1Meter) (1W/1Meter)
Power 5.25"= 5 - 40W 5.25"= 5 - 50W 5.25"= 5 - 60W
Handling 6.50"= 5-50W 6.50"= 5 - 65W 6.50"= 5 - 75W 6.50"= 5 - 85W
8"= 5 - 80W 8"= 5 - 90W 8"= 5 - 100W
