DMX Control & Selection
Please refer to the following table for the DMX control of the channel 1 of the
DMX controller.
DMX Values
of channel 1
10-19
20-29
30-39
40-49
50-59
60-69
70-79
Functions
0-9
Stand by
Scene 1
Scene 2
Scene 3
Scene 4
Scene 5
Scene 6
Scene 7
80-89
90-99
100-109
110-119
120-129
130-139
140-149
150-159
160-169
170-179
180-189
190-199
200-209
210-219
220-229
230-239
240-249
Pattern 1
Pattern 2
Pattern 3
Pattern 4
Pattern 5
Pattern 6
Pattern 7
Pattern 8
Pattern 9
Pattern 10
Pattern 11
Pattern 12
Pattern 13
Pattern 14
Pattern 15
Pattern 16
Pattern 17
250-255
T16F serves as a 4-
channel dimmer pack
and will be controlled by
the DMX controller
starting from the 2nd
channel
NOTE:
1. When the DMX value of channel 1 is within 0-9, the T16F will be in Stand by mode.
2. When the 1st DMX channel is set to 250-255, the T16F will serves as a 4 channel dimmer
pack, and be controlled by the DMX controller starting from the 2nd channel.
This Product must be earthed.
Disconnect power cable before opening.
To prevent fire or shock hazard, do not expose this product to a high
temperature or high humidity area.
WARNING!
Caution! No user serviceable parts inside, do not attempt repairs. In the event your unit
should fail, please contact your authorized dealer.
