23 PLATINUM FLX™ User Manual
ELATION© PLATINUM FLX™ S Y S T E M M E N U
Supports Software Versions: ≥ 1.5.2
MAIN MENU
SUB MENU
OPTIONS / VALUES
(Default Settings in BOLD)
DESCRIPTION
FUNCTION
Set DMX Address
A001~AXXX
DMX Address Setting
DMX Value
ALL……
DMX Value Display
Slave Mode
Slave1, Slave2, Slave3
Slave Setting
Auto Program
Master / Alone
Auto Program
INFORMATION
Time Information
Current Time
XXXX (Hours)
Fixture Run Time From Power ON
Total Run Time XXXX (Hours) Fixture Total Run Time
Last Run Time
XXXX (Hours)
Clear Fixture Last Run Time
Lamp Hours XXXX (Hours) Lamp Total Run Time
Lamp Off Time
XXXX (Minutes)
Lamp OFF Time
LastRun Password Password=XXX Password 038
Clear Last Run
ON / OFF
Reset Fixture Last Run Time
LampTimePassword
Password=XXX
Password 038
Clear Lamp Time
ON / OFF
Reset Lamp Run Time
Temperature Info
Head Temperature
XXX C° / F °
Temperature in Fixture Head
Ethernet IP
XXX . XXX . XXX . XXX
XXX . XXX . XXX . XXX
XXX . XXX . XXX . XXX IP Address
Fan Info
1U_FAN1: ~ 6U_FAN1:
Encode Info
PAN ENCODE:
TILT ENCODE:
Software Version
1U01: V1.5.2 ~ 6U:01: V1.5.2
Software Versions
Error Info
Error Record 1 ~ Error Record 10
Pan....
LAMP
CONTROL
Lamp ON/OFF
ON/OFF
Lamp ON/OFF
Automatic ON
ON/OFF
Lamp ON/OFF when Power ON
Lamp ON via DMX
ON/OFF
Lamp ON via DMX
Lamp OFF via DMX
ON/OFF
Lamp OFF via DMX
Max ON at Temp
20~79°C (45°C) / 68 ~ 174°F (113°F)
Lamp Restart at Temp
Lamp OFF Temp
80~139°C (130°C) / 176 ~ 282°F (266°F)
Lamp OFF at Temp
PERSONALITY
Status Settings
Address via DMX
ON/OFF
Address Via DMX
No DMX Status
Close/Hold/Auto
Auto Run If No DMX
Pan Reverse
ON/OFF
Pan Reverse Movement
Tilt Reverse
ON/OFF
Tilt Reverse Movement
Pan Degree
630/540
Pan Degree Select
Feedback
ON/OFF
Movement Feedback
Movement Speed
Speed 1 ~ 4
Movement Mode Select
Hibernation
OFF, 01M~99M, 15M
Stand By Mode
Service Setting
Password
Password=XXX
Service Password 050
RDM PID
XXXXX
RDM PID Code (PSWD Required)
Ethernet IP
XXX . XXX . XXX . XXX
Ethernet IP (PSWD Required)
Ethernet Mask IP
XXX . XXX . XXX . XXX
Ethernet Mask IP (PSWD Required)
Clear Err. Info
ON/OFF
Clear Error Info (PSWD Required)
DFLT Pow. LampOn
ON/OFF
Default Power Lamp ON
(PSWD Required)
Display Setting
Shutoff Time
02~60m 05m
Display Shut Off Time
Display Reverse ON/OFF Display Reverse 180º
Key Lock
ON/OFF
Key Lock
Temperature C/F
Celsius/Fahrenheit
Temperature Switch Betwee>RR
Initial Status
Auto Program...
Initial Effect Position
Select Signal
DMX Only
DMX Only
Art-Net on IP2
Elect Art-Net IP02
Art-Net on IP10
Elect Art-Net IP010
sACN
sACN Protocol
Set Universe
000 - 255
Set Art-Net Universe
Reset Default
ON/OFF
Password 011
Restore Factory Settings
