25 PLATINUM FLX™ User Manual
LAMP CONTROL - Lamp OFF Temp
The fixture is designed to shut the lamp OFF when an excessive temperature is
sensed inside the head by the on-board CPU. The lamp is shut OFF to prevent
damage to the lamp and avoid possible internal damage to the fixture head.
This function sets the MAX internal operating temperature of the fixture head when
the lamp will automatically be shut OFF.
PERSONALITY - Status Settings - Address Via DMX
When ON, define the desired DMX address via an external controller.
1. Connect the fixture to the external controller and power ON.
2. Set the DMX value of Channel 1 on the controller to (7).
3. Set the DMX value of Channel 2 on the controller to (7) or (8).
When set to (7), the DMX address can be set between (1) and (255).
When set to (8), the DMX address can be set between (256) and (511).
4. Using Channel 3 on the controller set the desired DMX address of the fixture.
Example 1:
If the desired DMX address is 57, set Channel 1 to a value of (7), set Channel 2 to
a value of (7), and then set Channel 3 to a value of (57).
Example 2:
If the desired DMX address is 420, set Channel 1 to a value of (7), set Channel 2 to
a value of (8), and then set Channel 3 to a value of (164). (256+164=420)
5. After setting Channel 3 to the desired DMX address value, wait for approximately
20 seconds for the fixture to complete the address reset function.
PERSONALITY – Service Setting - Password
Service Password - (050)
NOTE: The Service Password MUST be entered in order to access the following menus:
RDM PID, Ethernet IP, Ethernet IP Mask, Clear Err. Info, and DFLT Pow. LampOn.
