30 PLATINUM FLX™ User Manual
DMX CHANNEL FUNCTIONS AND VALUES - v1.3.0
ELATION© PLATINUM FLX™
DMX Channel Values / Functions (37 DMX Channels)
Supports Software Versions: ≥ 1.3.0
Features are subject to change without any prior written notice.
*Rotation direction (Clockwise or Counterclockwise) of effects depends on orientation of the fixture head and Pan/Tilt settings.
MODE / CHANNEL
VALUE FUNCTION
BASIC STAND EXTEND
1 1 1
PAN MOVEMENT [8 BIT]
0-255 PAN Movement
2 2
PAN FINE MOVEMENT [16 BIT]
0-255 Fine Control of PAN Movement
2 3 3
TILT MOVEMENT [8 BIT]
0-255 TILT Movement
4 4
TILT MOVEMENT [16 BIT]
0-255 Fine Control of TILT Movement
3 5 5
CYAN
0-255 0-WHITE - 255-100% CYAN
6
CYAN FINE
0-255 FINE Adjustment of CYAN
4 6 7
MAGENTA
0-255 0-WHITE - 255-100% MAGENTA
8
MAGENTA FINE
0-255 FINE Adjustment of MAGENTA
5 7 9
YELLOW
0-255 0-WHITE - 255-100% YELLOW
10
YELLOW FINE
0-255 FINE Adjustment of YELLOW
6 8 11
CTO COLOR
0-255 0-WHITE - 255-100% CTO
12
CTO COLOR FINE
0-255 FINE Adjustment of CTO
7 9 13
COLOR WHEEL
0-7 OPEN / WHITE
8-19 RED
20-31 BLUE
32-43 GREEN
44-55 YELLOW
56-67 MAGENTA
68-79 ORANGE
80-91 LT. BLUE
92-103
C T O
104-115 C T B
116-127 UV FILTER
128-189 *Clockwise Color Wheel Rotation from FAST to SLOW
190-193 NO Rotation
194-255 *Counterclockwise Color Wheel Rotation from SLOW to FAST
14
COLOR WHEEL FINE ADJUSTMENT
0-255 FINE Adjustment of Color Wheel to Any Position
