34 PLATINUM FLX™ User Manual
ELATION© PLATINUM FLX™
DMX Channel Values / Functions (37 DMX Channels)
Supports Software Versions: ≥ 1.3.0
Features are subject to change without any prior written notice.
*Rotation direction (Clockwise or Counterclockwise) of effects depends on orientation of the fixture head and Pan/Tilt settings.
MODE / CHANNEL
VALUE FUNCTION
BASIC
STAND
EXTEND
17 19 29
SHUTTER, STROBE
0-31
Shutter CLOSED
32-63 NO Function (Shutter OPEN)
64-95
Strobe Effect SLOW to FAST
96-127 NO function (Shutter OPEN)
128-159
Pulse Effect In Sequences
160-191 NO Function (Shutter OPEN)
192-223
Random Strobe Effect SLOW to FAST
224-255 NO Function (Shutter OPEN)
18 20 30
DIMMER INTENSITY
0-255 Intensity 0 to 100%
31
DIMMER INTENSITY FINE
0-255 Dimmer Intensity FINE Adjustment
19 21 32
FROST
0-127 OPEN
128-255
100% Frost
20 22 33
ANIMATION MOVEMENT SPEED
0-255
Animation Movement Speed from SLOW to FAST
21 23 34
CMY & COLOR MACRO SPEED
0-255
Speed FAST to SLOW
