35 PLATINUM FLX™ User Manual
ELATION© PLATINUM FLX™
DMX Channel Values / Functions (37 DMX Channels)
Supports Software Versions: ≥ 1.3.0
Features are subject to change without any prior written notice.
*Rotation direction (Clockwise or Counterclockwise) of effects depends on orientation of the fixture head and Pan/Tilt settings.
MODE / CHANNEL
VALUE FUNCTION
BASIC
STAND
EXTEND
22 24 35
C M Y & COLOR WHEEL MACROS
0-31 NO Function
32-39 Color Macro 1
40-47 Color Macro 2
48-55 Color Macro 3
56-63 Color Macro 4
64-71 Color Macro 5
72-79 Color Macro 6
80-87 Color Macro 7
88-95 Color Macro 8
96-103 Color Macro 9
104-111 Color Macro 10
112-119 Color Macro 11
120-127 Color Macro 12
128-135 Color Macro 13
136-143 Color Macro 14
144-151 Color Macro 15
152-159 Color Macro 16
160-167 Color Macro 17
168-175 Color Macro 18
176-183 Color Macro 19
184-191 Color Macro 20
192-199 Color Macro 21
200-207 Color Macro 22
208-215 Color Macro 23
216-223 Color Macro 24
224-231 Color Macro 25
232-239 Color Macro 26
240-247 Color Macro 27
248-255 Random C M Y
23 25 36
PAN / TILT MOVEMENT SPEED
0-225
MAX to MIN Speed
226-235 Blackout with PAN and TILT Movement
236-245
Blackout with ALL Wheel Movement
246-255 NO Function
