Elba EWF 1075 VT - Water Inlet Hose Connection Guide

2929
•Yourmachinemayhaveeitherasingleinlet
(cold)ordoublewaterinlets(cold/hot)basedonits
specications.
White-cappedhoseshouldbeconnectedtocold
waterinletandred-cappedhosetohotwaterinlet
(applicableformachineswithdoublewaterinlets).
•Toeliminatewaterleakagesinpointsofcontact,
1or2nutsareprovidedinthehosepackage(ap-
plicableformachineswithdoublewaterinlets).
Fitthesenutstotheendsofnewwaterinlethoses
onthesideoffaucet.
•Mountnewwaterinlethosestoa¾˝,threaded
faucet.
•Connectthewhite-elbowendofthewaterinlet
hosestothewhite-lteredwaterinletvalveonthe
rearsideofthemachineandthered-elbowendto
red-lteredone(applicableformachineswithdou-
blewaterinlets).
Tightenplasticpartsofthejunctionsusingyour
hand.
Inuncertainconditions,havetheconnectionworks
bedonebyaqualiedplumber.
•Flowofwaterwithpressureof0,1-1Mpawill
allowyourmachinetooperatemoreefciently.)
(0,1Mpapressuremeansthatmorethan8litres
ofwaterwillowthroughafully-tappedfaucetper
oneminute.)
•Ensurethatpointsofcontactdonotleakbytap-
pingthefaucetcompletelyaftercarryingmaking
theconnections.
CHAPTER -3: INSTALLATION OF THE MACHINE
(WATER INLET HOSE CONNECTION)
3/4”
10mm
