•Theendofwaterdischargehosecanbe
ttedtoaspecicapparatusdirectlyat-
tachedtodirtywaterdischargeholeor
outletjointofthebasinelbow.
•Neverattempttoextendthewaterdis-
chargehosebyjointing.
•Donotputdischarginghoseofyourma-
chineinavessel,bucketorsink.
•Makesurethatthewaterdischargehose
doesnotbend,buckle,becrushedorex-
tended.Pleasenote:
•Thewaterdrainhoseshouldbemounted
ataheightofminimum60cm,maximum
100cmfromtheground.
CHAPTER -3: INSTALLATION OF THE MACHINE
(WATER DISCHARGE CONNECTION)
~95cm ~140cm
~145cm ~95cm
0–max.100cm
˜
˜
95cm
150cm
