Elcometer 108 User Manual

R
15
6 TECHNICAL SPECIFICATION
6.1 PERFORMANCE
ANALOGUE INSTRUMENT
DIGITAL INSTRUMENT
6.2 PRESSURE RATING
Operating range: 0 MPa - 18 MPa (0 PSI - 2600 PSI)
Scale range: 0 MPa - 25 MPa (0 PSI - 3500 PSI)
Scale resolution: Metric (black) 1 division = 1 MPa
Imperial (red) 1 division = 100 PSI
Accuracy: Metric (black) 1 MPa
Imperial (red) 150 PSI
Operating range: 0 MPa - 18 MPa (0 PSI - 2600 PSI)
Scale range: 0 MPa - 34 MPa (0 PSI - 5000 PSI)
Scale resolution: 0.05 MPa (7 PSI)
Accuracy: ±3% or 60 PSI (whichever is the greater)
Rubber hose: 34 MPa (5000 PSI), Working
138 MPa (20 000 PSI), Burst
Connector: 41 MPa (6000 PSI), Working
103 MPa (15 000 PSI), Leak
