Putting the Telephone into Operation
26
Wall installation
Feed the guide tabs (1) on the wall−mounting bracket (2) in the slots (3) on
the underside of the telephone. Slide the wall−mounting bracket 10 mm
upwards until it audibly locks into place. Drill a hole and insert a screw
leaving about 5 mm of the screw projecting from the wall. Guide the
mounting hole (4) in the mounting bracket (2) over the screw and slide the
telephone downwards.
Caution: Ensure there are no electrical cables, water pipes etc.
in the wall where the hole is drilled.
1
2
3
3
4
Turn the hook (5) in the receiver cradle so that the receiver can be placed
on−hook.
5
5
5
5
5
