TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
XPLORE RANGE (continued)
Model 540 556
Number of Berths 4 6
Interior Length 5599mm (18’5”) 5599mm (18’5”)
Exterior Body Length 6420mm (21’1”) 6420mm (21’1”)
Shipping Length 7341mm (24’1”) 7341mm (24’1”)
Overall Width 2146mm (7’0.5”) 2146mm (7’0.5”)
Overall Height 2726mm (8’11”) 2726mm (8’11”)
Maximum Headroom 1908mm (6’3”) 1908mm (6’3”)
Interior Width 2032mm (6’8”) 2032mm (6’8”)
Wheel Rim 5.5J x 14 5.5J x 14
Ty re Size 175 R 14 99 175/65 R 14 99
Ty re Pressure at MTPLM in psi 60 60
Brake Size 200/50 200/50
Awning Sizes Ground to Ground 9950mm (32’1”) 9950mm (32’1”)
Front Bed Sizes 1 x Double 2 x Single
2000mm x 1240mm 1830mm x 673mm
(6’6” x 4’1”) (6’0” x 2’2.5”)
or
1 x Double
1980mm x 1375mm
(6’6” x 4’6”)
Side Dinette Not Applicable Not Applicable
Rear Bed Sizes Fixed Bed Fixed Bunks
1 x Double 3 x Single
1830mm x 1270mm 1830mm x 610mm
(6’0” x 4’2”) (6’0” x 2’0”)
1 x Single
1800mm x 630mm
(5’11” x 2’1”)
Maximum Hitch Weight 100kgs (1.96cwt) 100kgs (1.96cwt)
Mass in Running Order 1222kgs (24.00cwt) 1211kgs (23.78cwt)
Optional Equipment Payload 23kgs/0.45cwt 23kgs/0.45cwt
Maximum User Payload 178kgs (3.49cwt) 198kgs (3.89cwt)
Plated M.T.P.L.M. 1400kgs (27.5cwt) 1410kgs (27.69cwt)
Max M.T.P.L.M. 1500kgs (29.46cwt) 1500kgs (29.46cwt)
Note 1: If you require a larger payload it is possible to upgrade the Plated Maximum Technical Permissible Laden Mass. Please contact
your supplying retailer for more information.
Note 2: The Mass in Running Order includes a manufacturing tolerance for material variances and 28kgs for 2 x 5kg BP Gas Light
bottles and 10 litres of water in the water heater and 2 litres of water in the toilet.
Note 3: Maximum User Payload includes the Personal Effects Payload and the Optional Equipment Payload.
Note 4: Please take care to ensure that you have allowed for the masses of all items you intend to carry in the caravan.
Note 5: All data is calculated using metric weights and measurements. The imperial figures quoted are conversions thereof.
Note 6: The internal length is measured at 320mm above the floor level..
Note 7: Warning under no circumstances must the plated MTPLM of the caravan be exceeded.
