elddis Buccaneer 2014 - Windows; Polyplastic Window Opening; Seitz Window Opening

8-22
HOW TO USE YOUR CARAVAN’S EQUIPMENT
Keep button pushed in, then turn
handle
Polyplastic Window Opening
(i) In order to open the Polyplastic window it
is only necessary to move the catch
upwards and release the catch from the
backing plate.
(ii) The Polyplastic window should remain in
the open position once opened, however
if it does not then tighten the friction
control on the window stays to increase
the holding force.
(iii) The Polyplastic window is also fitted with
a night ventilation position where the
catch is set to the centre position on the
backing plate; in this position it may be
possible for rain to enter the caravan in
adverse conditions.
Seitz Window Opening
(i) In order to open the Seitz window you
must depress the button on the catch
before moving the catch. Failure to do so
will lead to the catch breaking.
(ii) Seitz windows will automatically stay
open once open due to the built in ratchet
within the stay.
(iii) In order to close the window it is
necessary to open the window fully then
close the window in one steady
movement before closing the stays when
the button should click into the locked
position.
WINDOWS
Your caravan will be fitted with either Polyplastic; Seitz framed windows, or a mixture of both.
