5-8
ARRIVING ON SITE
Then the other axle support can be extended by holding button “LEFT
SIDE” (no.10) or “RIGHT SIDE” (no.13) pressed down. The levelling
procedure automatically stops when the caravan is levelled in the left right
direction. The ORANGE arrow level LED (no.14) goes out.
Step 4 Press the button “FRONT SIDE” (no.12) and hold it pressed down till the
ORANGE arrow level LED (no.14) goes out, extending of the front corner
supports stops by itself when the caravan is levelled in the front to rear
direction.
Step 5 Press the button “REAR SIDE” (no.11) until the corner supports at the rear
side are touching the ground. Attention: The level system does NOT stop
automatically.
Step 6 Press 1x on the button “ON/OFF” (no.5) to switch the levelsystem OFF.
9
LEFT SIDE
(no.10)
INDICATOR LED
(no.14)
RIGHT SIDE
(no.13)
FRONT SIDE
(no.12)
INDICATOR LED
(no.14)
REAR SIDE
(no.11)
9
