7-2
ELECTRICAL SYSTEM
it may trip the site circuit breaker. Please
check the available mains output with your
site operator. The following items need to be
added together if used simultaneously.
230V mains equipment typical consumption
figures:
• Refrigerator ............................... 0.50 amps
• Charger ..................................... 0.50 amps
• Water heater ............................... 3.9 amps
• Blown air heaters ........................ 8.5 amps
• Colour TV .................................. 3.33 amps
• Microwave ................................. 4.00 amps
• Air conditioning ......................... 4.00 amps
AUTOMATIC CHARGING SYSTEM
The battery charger will operate automatically
when the caravan is connected to the mains
outlet on a caravan site. The 12V system,
with the exception of the 12V refrigerator and
battery charging, will not operate when the
caravan is connected to the towing vehicle.
CHECK all caravan equipment is set-up to
accept the site supply before actually
switching on.
MAXIMUM BULB RATINGS FOR
INTERNAL LIGHTS
Type of Light Maximum Bulb Rating
Compact Fluorescent .............................. 9W
Reading Lights ...................................... 10W
Downlighters ......................................... 10W
MAXIMUM BULB RATINGS FOR
ROAD LIGHTS
Type of Light Maximum Bulb Rating
Front position .......................................... 5W
Brake/Rear position ........................ 21W/5W
High level marker .................................... 5W
Indicator ................................................ 21W
Reversing .............................................. 21W
Please note: Ensure that you only replace a
blown bulb with one of the same rating.
Never replace a bulb with one with a higher
rating. You should ensure that when fitted, no
bulb is in contact with the surface of the lamp
or shade.
CAUTION: The reading lights will become
hot when in use. Do not touch the bulb when
they are illuminated and allow sufficient time
for them to cool after switching off. It is
recommended to set the position of the
reading light before switching on.
CAUTION: Do not look directly at LED lights.
