USER MANUAL ELDES ESIM251 V1.0
27
XXXX_
SMSEXTRA:
Z2:SS,SC,
CC,SE,SD
FOR ADVANCED USERS
All these features can be congured using program “ELDES Conguration Tool“
3.9.2 Additional possibilities of controlling and conguring controller C1 (relay output)
Normally C1 output can be controlled only by SMS message, as described in chapter 3.6, i. e. by enabling/disabling it for a perma-
nent status or for a preset period. However, you can congure automatic enabling and disabling for a particular hour or control this
function by a call.
3.9.2.1 Settings of an output controlled by calls
When calling on the number of system ESIM251 the call is rejected and no control operations are run. However, when a special
mode is enabled C1 output can be controlled by a call. It can be controlled by all users NO1-NO5, several users or only one of them.
By calling the system you can enable these 3 functions: enable/disable, enable/disable for a certain period or change output status
witheverycall,i.e.onecallenablesthestatus,thenextonedisablesitetc.
The parameters are changed by sending the following SMS message to the system ESIM251:
XXXX–userpassword.ValuestructureisCnVal,whenCniscommandname(2letters),andVal-itsvalue).
Value (CnVal) – table of values
Cn – command
name (2
letters)
Val – possible
command
meaning.
Command
description
Initial factory
default values
Comments
Enabling control
via call
CE 1,2,3,4,5
Control via call mode
is enabled for users
No:1,2,3,4,5
E. g. CE25 means that users NO2 and NO5 will be
able to control the output via call.
CD 1,2,3,4,5
Control via call modes
is disabled for users
No:1,2,3,4,5
CD12345
Disabled for all
users NO1-NO5.
E. g. CD25 means that output control via call is
disabled for users NO2 and NO5.
Enabling/
disabling
conrmation call
(CallBack)
CS 1,2,3,4,5
Conrmation call
mode is enabled for
users No:1,2,3,4,5.
E. g. CS124 means that when users NO1, NO2 and
NO4 control the output via call they will be notied
about a successful output status change by a
conrmation call.
CC 1,2,3,4,5
Conrmation call
mode is disabled for
users No:1,2,3,4,5..
CC12345
Disabled for all
users NO1-NO5.
E. g. CC124 means that when users NO1, NO2 and
NO4 control the output via call the call conrming
about a successful output status change is disabled
and users will not receive calls.
Conrmation
call duration
parameters
CT
1,2,3,4,5;1; s
Conrmation call
is made for users
No:1,2,3,4,5 when the
ouput is turned on.
s- call time in seconds
СT112
СT212
СT312
СT412
СT512
The rst number refers to user number. The second
number is a command and the last number refers
to call time in seconds.
E. g. СT412 means that if conrmation call mode
is enabled, user NO4 will receive a call if he/she is
trying to turn on the relay. The system will call for
2 seconds.
1,2,3,4,5;0; s
Conrmation call
is made for users
No:1,2,3,4,5 when the
output is turned o.
s- call time in seconds
СT108
СT208
СT308
СT408
СT508
The rst number refers to user number. The second
number is a command and the last number refers
to call time in seconds.
E. g. СT408 means that if conrmation call mode
is enabled, user NO4 will receive a call if he/she is
trying to turn o the relay. The system will call for
8 seconds.
Enabling/
disabling
conrmation
SMS
(SMSconrm)
SS 1,2,3,4,5
Conrmation SMS
mode is enabled for
users No:1,2,3,4,5.
E. g. SS124 means that when users NO1, NO2 and
NO4 control the output via call they will be notied
about a successful output status change by a
conrmation SMS message.
Before that the user has to turn on control from a
particular number by using CE command.
SC 1,2,3,4,5
Conrmation SMS
mode is disabled for
users No:1,2,3,4,5.
SC12345
Disabled for all
users NO1-NO5.
E. g. SC124 means that when users NO1, NO2 and
NO4 control the output via call the conrmation
SMS message informing about the successful
output status change is not sent.
XXXX_SMSEXTRA:COC:Value1,Value2,……,ValueN
