USER MANUAL ELDES ESIM251 V1.0
29
FOR ADVANCED USERS
All these features can be congured using program “ELDES Conguration Tool“
Value (CnVal) – table of values
Cn – command
name (2 letters)
Val – possible
command
meaning.
Command description
Initial factory
default values
Comments
Enabling/
disabling
conrmation call
(CallBack)
CB 1
Conrmation call mode
is enabled for all users.
CB1 means that when users control the
output via SMS message they are notied
about a successful output status change
by a conrmation call.
CB 0
Conrmation call mode
is disabled for all users.
CB0
Disabled for all
users NO1-NO5.
CB0 means that when users control
the output via SMS message they will
not receive a call informing about a
successful output status change.
Conrmation call
duration
CT
1; s
All users receive
conrmation call when
the output is enabled;
s- call time in seconds
СT12
The rst digit is a command; the last digit
refers to call time in seconds. E. g. СT12
means that if conrmation call mode is
enabled the call will be forwarded to the
user who is trying to turn on the relay.
The system will call for 2 seconds.
0; s
All users receive
conrmation call when
the output is disabled;
s- call time in seconds
СT08
The rst digit is a command; the last digit
refers to call time in seconds. E. g. СT08
means that if conrmation call mode is
enabled the call will be forwarded to the
user who is trying to turn o the relay.
The system will call for 8 seconds.
Enabling/
disabling
conrmation
SMS message
(SMSconrm)
SB 1
Conrmation SMS
mode is enabled for
all users.
SB1
Enabled for all
users NO1-NO5.
SB1 means that when all users control
the output via SMS message they will
be informed about a successful output
status change by a conrmation SMS
message.
SB 0
Conrmation SMS
mode is disbled for all
users.
SB0 means that when all users control
the output via SMS message they will not
be informed about a successful output
status change by SMS message.
Example of SMS message conguring C1 output ways of information:
This message congures C1 output parameters when controlled via SMS messages.
CB1 means that when the user enables/disables output С1 he/she receives ashort conrmation call CALLBACK.
CT13 means that when the relay is enabled conrmation call duration is 3 seconds.
CT06 means that when the relay is disabled conrmation call duration is 6 seconds.
SB1 means that conrmation message is sent informaing about enabling/disabling.
To see the preset values for any command send SMS message with the same format that you use when changing parameters; only
Value structure will have no value:
XXXX–userpassword.ValuestructureisCnVal,whenCniscommandname(2letters).
E. g. XXXX_SMSEXTRA:OCS:CB,CT,SB
XXXX_SMSEXTRA:OCS:CB1,CT13,CT06,SB1
XXXX_SMSEXTRA:OCS:Value1,Value2,……,ValueN
