ELECRAFT K2 - Page 2

MENU COMMANDS
ST L / ST P: Set Side Tone [L]evel / [P]itch
Select with main knob, BAND+ or BAND-,
Hold EDIT to change:
t-r: QSK delay. 0.02 Default rPt: CW message Repeat intrvl iAb: iambic A or B
inP: Paddle hand, normal, reverse LCd: night-backlight on, day off GrPH: dOt, bAr, OFF
CAL: Off, FCtr, FIL, PLL, CUR, S LO, S HI PF1/2: Select User-programmed Function PF1/2
SSbA: Audio, SSbC: Speech
Compressor
rAnt: Aux Rec Ant switch OFF, ON
per Band
OPt: Perf, Battery
ATU: Automatic Tuning Unit L0-L8 / C0-C8: Test individual ATU element
AUTO: Normal auto-tune; use with most antennasCALn: Used for calibration of C55 (null). L/C set
to 0; network set to Cin.
POUT: Forward/Reverse power display
CALP: Used for calibration of R1. L/C set to 0;
network set to Cin.
ALT: Alternate auto-tune; use with short whips, etc.
(much longer tune times)
Lxx.x / Cx.xx: Ind(uH)/Cap(nF) in use***CALS: Used to check SWR calibration. L/C set
to 0; network set to Cin.
x.x-1: SWR from most recent tune-up***
INFO CODES: 010 Battery Voltage too low, 80 IOC Problem, 81 AuxBus Problem, 90/91 EEPROM write
test failed, 201 EEPROM initialized, 230 BFO not connected to Freq Cntr, 231 VCO not connected to
Frequency Counter, 235 PLL Ref Oscillator range error,
***(stored per-antenna, per-band)
BAND LISTING (Band, Band Segments, QRP Calling Frequencies-Novice, Europe, PSK31)
CW SSB
160 1.8 1.81 1.838 1.843 1.91 2.0
80/75 3.5 3.56 3.579 3.58 3.71 3.75 3.69 3.985 4.0
40 7.0 7.035
7.04
7.080
7.035
7.03
7.06
7.110
7.112
7.15 7.09 7.285 7.3
30 10.1 10.106 10.116 10.140 10.15
20 14.0 14.06 14.070 14.15 14.285 14.35
17 18.068 18.096 18.100 18.11 18.13 18.168
15 21.0 21.06 21.110 21.080 21.2 21.285 21.385 21.45
12 24.89 24.906 24.920 24.93 24.95 24.990
10 28.0 28.06 28.110 28.120 28.3 28.36 28.385 28.885 29.7
K2 28.715
