wire free at one end. Then solder the twisted wires together right at the jack.
5. Connect the free end of the mic jack ground wire to the short ground jumper that is located
along the nearby edge of the front panel board. Solder the mic ground wire to the ground
jumper.
6. Clip any excess wire. Re-attach the front panel assembly to the K2 chassis.
7. Plug in the mic and measure the resistance from the mic plug to the K2's chassis ground. It
should be very low (< 10 ohm).
