Appendix A K2 Misc. Bag Parts List (p/n E850004)
PICTURE Designators Value Description Part Number
QTY
Appendix A K2 Probe Assemblies Parts List (p/n E850036 envelope in E850004 Misc bag)
PICTURE Designators Value Description Part Number
QTY
FCP-C1 10pf cap Axial Leads (like a resistor); counter probe E530067
1
RFP-C1 .01 µF cap Monolithic capacitor, for optional RF probe E530009
1
RFP-D1 1N34A diode For RF probe; germanium E560000
1
FCP-E1 1 pin male probe tip For counter probe E620044
1
FCP-J1, VMP-J1 2 pin female housing For counter and voltmeter probes E620021
2
Misc female crimp pins For counter and voltmeter probes E620022
3
Misc Aligator clip, insulated For RF probe (ground) E700074
1
Misc Banana plug, red For RF probe (DMM positive lead) E700076
1
Misc Banana plug, black For RF probe (DMM negative lead) E700075
1
RFP-R1 4.7M Resistor 5%, 1/4W; For RF probe E500048
1
Appendix A K2 Wire Bag Parts List (p/n E850005 bag)
PICTURE Designators Value Description Part Number
QTY
Misc #26 Red Enamel Wire For toroids E760002
30 ft
Misc #28 Red Enamel Wire For L33 (BFO); bagged separately E760003
3 ft
Misc #26 Green Enamel Wire For toroids E760004
8 ft
Misc
Green solid hookup wire,
#24 Insulated wire for T4, misc. wiring E760008
3 ft
Misc
White solid hookup Wire,
#24 Insulated wire for T4, misc. wiring E760013
1 ft
Misc
Black stranded hookup
wire, #24 For RF probe E760016
6"
Misc RG174 Coax Cable For counter and RF probes E760010
3 ft
Misc
#24 Dual-conductor
speaker wire For speaker and ext. speaker jack E760012
2 ft
Misc Grill Cloth Must be cut to speaker size; see text E850089
3x3"
Misc Heat Shrink; 3/16" dia. For counter probe. E980028
4"
