15
CONTROL BOARD (Front panel removed except ** = CAL FCTR mode w/front Panel plugged in; * = approximate and/or may fluctuate)
Ref. Pin VDC Ref. Pin VDC Ref. Pin VDC Ref. Pin VDC Ref. Pin VDC Ref. Pin VDC
Q1 E 8.0 Q12 E 6.3 U6 1 5.0 U6 34 0.0 U9 1 0.4*
B 8.0 B 7.0 2 0.0* 35 0.2* 2 .02*
C 0.0 C 8.0 3 5.0* 36 0.8* 3 .02*
Q2 E 8.0 U1 1 1.4 4 0.2* 37 5.0 4 0.0
B 7.3 2 1.4 5 2.6* 38 1.2* 5 0.0
C 7.5 3 0.0 6 4.7* 39 0.2* 6 6.7
Q3 S 0.0 4 6.9 7 0-5* 40 5.5 7 13.7
G 0.0 5 6.9 8 0-5* U7 1 5.0 8 6.8
D 8.0 6 8.0 9 0 or 5 2 5.0 U10 1 7.7*
Q4 S 0.0 7 7.5 10 5.0** 3 5.0 2 5.0*
G 5.0 8 8.0 11 5.0 4 0.0 3 5.0*
D 0.0 U2 1 6.9 12 0.0 5 5.0 4 8.0
Q5 S 0.0 2 6.9 13 2.3* 6 0.0 5 5.0
G 0 or 5 3 6.9 14 2.4* 7 5.0 6 5.0
D 0-5 4 0.0 15 2** 8 5.0 7 5.0
Q6 G 2.7* 5 7.3 16 0-5* U8 1 0-5* 8 0-8*
S 5-6* 6 7.3 17 2.7* 2 5.0** 9 0-8*
D 5-6* 7 7.3 18 0.0 3 5.0 10 0-8*
Q7 G 2.7* 8 8.0 19 5.0 4 0.0 11 0.0
S 5-6* U3 1 0.4* 20 5.0 5 0.0 12 0-8*
D 5-6* 2 13.7 21 5.0 6 5.0 13 0-8*
Q8 E 7.0** 3 13.7 22 5.0 7 5.0 14 0-8
B 7.7** 4 0.0 23 5.0 8 0 or 5
C 8.0** 5 2.5 24 5.0 9 5.0
Q9 E 0.0 6 2.5 25 0.0 10 0.0
B 0.7** 7 2.5 26 5.0 11 5.0
C 2 ** 8 13.7 27 0.0 12 0.0
Q10 E 0.0 U4 IN 13.7 28 5.0 13 5.0
B 0.7** GND 0.0 29 5.0 14 0.0
C 2** OUT 8.0 30 5.0 15 0-5*
Q11 E 0.2* U5 IN 13.7 31 0.0 16 0-5*
B 0.9* GND 0.0 32 5.0
C 13.5 OUT 5.0 33 5.0
