Your Elecro heater must be screw fixed to a firm base or wall. The heater MUST be
horizontal and upright i.e. with the control enclosure located above the Titanium
flow tube (see diagram below). Under no circumstances should the heater be oper-
ated in any other orientation.
NB Diagrams do not show
the digital thermostat
POSITIONING
The heater can be installed on both pump and gravity fed systems. It should
be installed at a low point in the filtration system. To limit weed and debris
build up inside the heater it must be sited after, i.e. downstream, of the filter.
NOTE If the
flow direction
is reversed
(explained
later in this
booklet) the
heater MUST
remain sited
after the filter.
Only clean filtered water
should enter the heater.
NOTES
[Blank Page For Your Notes]
