EN - 11
2.1 Dimensions
H1
H2
Space required in use
2
H2 mm 988
W2 mm 640
D2 mm 692
Overall space required in use
3
W3 mm 658
D3 mm 1134,5
Overall dimensions
1
H1 mm 838
W1 mm 540
D1 mm 595
W1
D1
W2
D2
W3
D3
