Electra EMD 27 - Configuration of the Appliance; Remote Control Dip Switch Setting

7-5
CONTROL SYSTEM
Revision Y05-01Service Manual - EMD Series
CONFIGURATION OF THE APPLIANCE
REMOTE CONTROL DIP SWITCH SETTING
DEFINITIONSETTING SWITCH STATUS
RC4RC3SW. NO.4SW. NO. 3SW. NO. 2SW. NO. 1
RC-ALL MODES OF OPERATION__
OFF
OFF
STD-COOL, FAN, DRY, ACTIVE__
OFF
ON
HEAT-COOL, FAN, DRY, ACTIVE__
ON
OFF
AUTO FAN (AF)__
ON
ON
VERTICAL SWING ONLY
TEMP. DISPLAY IN qC DEGREES
_OFF
_
_
HORIZONTAL & VERTICAL SWING
FUNCTIONS TOGETHER
TEMP. DISPLAY IN qF DEGREES
_ON
_
_
DISABLE LCD &
KEY ILLUMINATION
TIMER & CLOCK 12 H AM, PM
OFF_
_
_
ENABLE LCD &
KEY ILLUMINATION
TIMER & CLOCK 24 H
ON
_
_
_
RESET OPERATION - Press at the same time the 4 buttons :“CLEAR “, “SET” ,
"HR +”, “HR -” for 5 seconds
LEGEND:
SW1, SW2 - SELECTION OF RC/ST
SW3 - SELECTION OF TEMP. DISPLAY qC or qF IN RC3 OR SWING FUNCTION IN RC4.
SW4 - SELECTION OF TIME DISPLAY 12H AM/PM or 24H IN RC3 0R ILLUMINATION FUNCTION IN RC4.
OFF = 0
ON =1
NOTE: After setting the dip switches perform reset operation..
