Rascal Veo, Veo X & Veo Sport Scooter
Scooter Diagnostic Functions
Your Scooter Controller provides diagnostic information in the form of flash-codes. The first LED on the battery
indicator flashes to indicate a problem has been detected. On switching on, the controller conducts a
diagnostic test. If there is a fault, the first lamp/LED in the battery indicator will flash a sequence of flashes to
indicate what the fault is. There will be two groups of flashes separated by a 2 to 3 second pause. Count the
number of flashes in each group and decode the fault using the table below.
Number Indicated fault Possible cause
of Flashes
4,5 Battery disconnected 1. Battery not connected.
2. Poor connection to battery terminals.
4,4 Motor Open 1. Incorrect motor wiring.
2. Motor defective.
3,4 Brake Off fault 1. Electromagnetic brake driver open.
2. Electromagnetic brake coil shorted.
3,2 Brake On fault 1. Electromagnetic brake driver shorted.
2. Electromagnetic brake coil open.
4,1 Current sense out of range 1. Short in motor or in motor wiring.
2. Controller failure*
4,3 EEPROM fault 1. EEPROM failure or fault.
4,2 Motor voltage out of range 1. Motor voltage does not correspond to throttle request.
2. Short in motor or in motor wiring.
3. Controller failure*
3,5 HPD (High Pedal Disable) 1. Improper sequence of throttle and KSI, push,
or inhibit inputs.
2. MIsadjusted throttle pot.
2,3 Main contactor fault 1. Main contactor welded or stuck open.
2. Main contactor driver fault.
2,2 Motor stalled 1. Motor blocked/stalled.
2. Motor defective.
2,1 Main contactor driver 1. Main contactor driver failed open.
Off fault
* Jack the vehicle and retest to confirm diagnosis. Clean connections, inspect system wiring, and retest.
