2.3 Alarm An alarm condition will be caused by a smoke / heat detector, a break glass unit or some other
sensing unit detecting a fire risk situation. The sounders will operate and the internal buzzer will
sound. The display of the units in alarm is similar to that of the fault display. All alarms will override the
fault display. The zone display (5) indicates the initial zone of alarm and the fire LEDs above the zone
will flash. If another alarm condition occurs the zone display indicates the new zone momentarily and
then reverts to initial zone of alarm. A new zone of fire is indicated by the internal buzzer pulsing for 2
seconds before returning to a continuous tone. The time and date location (3) displays a fault and
alarm count, which indicates the number of alarms and faults presently on the system (not available
on the EDA-M200). All zones that are in alarm are listed on the top middle portion of the display (2).
For the EDA-M200 the top 2 lines contain the first zone of alarm, the last zone of alarm and the total
number of zones in alarm.
If a smoke detector only sends a single alarm message and does not follow up to complete the alarm
verify then a pre alarm event is generated in the event log but not displayed.
Rx Zones in Alarm 12:33:29
Tx 056 001 004 051 21-11-99
1 Fire Zone 056 Callpoint 034 12:33 21-11-99
1st Floor South Wing Fire Escape by Room 12
2 Evacuate Control 0001 12:39 21-11-99
Ground Floor Main Entrance Behind Reception
Example - Alarm Display for EDA-M100 and EDA-M150
1ST ZN LAST ZN TOTAL
04 04 01
1 ZONE 04 HEAT 003
Second floor outside
Example - Alarm Display for EDA-M200
Text Line scrolls across
the LCD
Text Line scrolls across
the LCD
