Radio Fire Alarm System – User Manual Page:7
V301_user Feb 2009
Electro-Detectors
3.0 Advanced Operation
This section details use of the menus and the functions available to a user. A password is required to perform
these functions. There are two levels of access, i/ a user and ii/ an engineer. The default user password for a newly
supplied panel is 2222. If the password is forgotten an engineer will be required to gain access to the system to
alter the user password.
3.1 Main Menu
To enter the menu system, press the button labelled MENU. This function is disabled if the system is in an alarm
condition. The display will prompt the user to enter a four digit password. There are five attempts to enter the
correct password. If after five times the password is still not correct, the menu button will be disabled for thirty
minutes.
If the menu system is entered and no keys are pressed for five minutes the panel will exit the menu and return to
normal operation.
Once entered correctly the system will display momentarily that entry has been granted to a user and how many
failed access attempts have been made since the last entry. The main menu, detailed below, will now be displayed.
All menus operate in the same basic manner. The highlighted bar can be moved up and down using the ∧ and ∨
keys. Pressing enter will then select this option. The scroll bar will wrap round the screen. For example, to select
Change Options press the ∨ key until Change Options is highlighted and press Enter. Alternatively the number
preceding the option can be pressed for fast access. On the M200 panel the menu bar is not featured and
therefore the menu item must be selected using the numeric keys.
To exit completely from the menus to the system display repeatedly press cancel.
To return to the previous menu press 0.
Alarms will override the menu system. New faults will cause the buzzer to sound and the appropriate LED’s
illuminate but will not override the menu. The buzzer can be silenced by pressing silence. The faults will be
displayed when the user exits the menu.
MAIN MENU
1. Isolate / Enable
2. Test Modes & Options
3. Change Options
4. View Event Log
0. Exit
Use ↑↓ to highlight and press enter to select
Main Menu for EDA-M100 and EDA-M150
1.Isol Dev 5.Test
2.Isol Zone
3.Isol Aux Cancel
4.Event Log -Exit
Main Menu for EDA-M200
