EXT FOOTSWITCH FUNCTIONS
The EXT input jack on the PITCH FORK
®
+ provides expanded control with
an external foot controller, such as the EHX Triple Foot Controller or
Digitech
®
FS3X. Using a TRS cable, connect the foot controller to the EXT
input. Now use the external foot controller to change modes, enter/exit
sub-menus, load presets, and scroll through parameter values.
The foot controller has three footswitches, Mode (Tip), Up (Ring) and
Down (Tip+Ring). The footswitches function as follows:
MODE (Tip) – This footswitch can be used to cycle through the eight
Mode buttons, enter/exit a sub-menu and load presets.
• Cycle through modes: A single press when a mode main-menu is
displayed selects the next mode button.
• Enter sub-menu: Quickly double press the mode footswitch.
• Exit sub-menu: Single press to go back one menu level.
UP (Ring)/DOWN (Tip+Ring) – These two footswitches can be used
for scrolling through parameter values and menus:
• Increment: A single press and release on the Up footswitch
increments the current parameter value by one.
• Decrement: A single press and release on the Down footswitch
decrements the current parameter value by one.
• Quick Scroll Increment: Press and hold the Up footswitch to scroll
upwards through values at a faster rate for certain modes and
sub-menus listed below.
• Quick Scroll Decrement: Press and hold the Down footswitch to
scroll downwards through values at a faster rate for certain modes
and sub-menus listed below.
Quick scrolling works within the following modes/menus: SHIFT 1&2,
DETUNE 1&2, JUMP, 1->2, 1<-2, PRESET, RISE and FALL. While quick
scrolling in PRESET mode, once the desired preset is reached, tap either
UP or DOWN to load the selected PRESET if it is valid. A valid/non-empty
preset slot will have a dot in the lower right corner.
