V. Specifications: Non-amplified Photodetectors
A. Silicon Photodetectors:
Part No. (Model)
120-10011-0001
(ET-2030)
120-10028-0001
(ET-2040)
120-10133-0001
(ET-2060)
120-10134-0001
(ET-2070)
Rise Time/Fall Time
<300ps/<300ps
<30ns/<30ns
<320ps/<320ps
3ns/3ns
Responsivity at 830nm
0.47A/W
0.6A/W
0.47A/W
0.56A/W
Power Supply
9VDC
24VDC
9VDC
24VDC
Bandwidth
>1.2GHz
>25MHz
>1.1GHz
>118MHz
Active Area Diameter
0.4mm
4.57mm
0.4mm
2.55mm
Dark Current
<0.1nA
<10nA
<0.1nA
<10nA
Acceptance Angle (1/2 angle)
10⁰
60⁰
N/A
50⁰
Noise Equivalent Power
<0.01pW/√Hz
<0.09pW/√Hz
<0.01pW/√Hz
<0.10pW/√Hz
Maximum Linear Rating
CW current: 3mA
Pulse current: 3mA
CW current: 2mA
Optical input: 3mW
CW current: 3mA
Optical Input: 3mA
CW current: 2.5mA
Pulse current: 15mA
Mounting (Tapped Holes)
8-32 or M4
8-32 or M4
8-32 or M4
8-32 or M4
Output Connector
BNC
BNC
BNC
BNC
B. InGaAs Photodetectors:
Part No. (Model)
120-10034-0001
(ET-3000)
120-10050-0001
(ET-3010)
Rise Time/Fall Time
<175ps/<175ps
<175ps/<175ps
Responsivity at 1300nm
0.9A/W
0.85A/W
Power Supply
6VDC
6VDC
Bandwidth
>2GHz
>1.5GHz
Active Area Diameter
100µm
100µm
Dark Current
<2.0nA
<1.0nA
Acceptance Angle (1/2 angle)
20⁰
N/A
Noise Equivalent Power
<0.03pW/√Hz
<0.02pW/√Hz
Maximum Linear Rating
CW current: 5mA
CW current: 5mA
Mounting (Tapped Holes)
8-32 or M4
8-32 or M4
Output Connector
BNC
BNC
