4
Most operation and troubleshooting information is displayed on the LCD display panel.
Following is the description of display screens and what they mean.
RED LED blinks for warning and is solid for errors
OPERATION
Treatment terminates in ERROR condition for reasons listed below. To clear error condition
after corrective action is taken, hold mode/reset button on display for four seconds.
Following screens can be seen by scrolling up (>) and down (<) keys. These screens display historical summaries
of the data and allow setting of clock and flush timers
TIME 00:00:00
DATE: 01/01/00
FLUSHTIME 1
05
FLUSHTIME 2
10
NUMBER OF CYCLES
00100
NUMBER OF RESETS
00
CYCLE W/O LST
000
LOW AMP 14-18
000
LOW AMPS 7-14
000
LOW AMP SHUTDOWN
000
LOW VOLTS < 90%
05
LOW VOLT < 83%
01
MIN TEMPERATURE
20
LOW VOLT SHUTDOWN
05
MAX TEMPERATURE
90
Display Panel LEDS Status
Green
Red
Previous cycle ended normally Ready for next cycle
Previous cycle completed with low voltage, Ready for next cycle,
low voltage should be corrected
Previous cycle completed with low electrode amps, Ready for
next cycle, low amps should be corrected
Unit is in pretreatment cycle after start, voltage displayed,
Unit goes to treatment cycle after pretreatment for 120 seconds,
voltage and amps are displayed alternately.
During the treatment cycle if electrode amps drop below 14,
Warning is displayed, and cycle is extended up to 240 seconds
During the entire cycle if voltage drops below 89% of full battery
voltage, warning is displayed, cycle continues
READY TO FLUSH
****WARNING****
VOLTAGE LOW
**PRETREATMENT**
VOLTAGE= 100%
***TREATMENT***
VOLTAGE= 100%
***TREATMENT***
AMPS = 15
****WARNING****
AMP = 10
****WARNING***
VOLTAGE< 87%
****WARNING****
AMPS< 14
Voltage was less that 83% of full voltage during the cycle; check
battery , connections and wire sizes.
*****ERROR****
LOW VOLTAGE
*****ERROR*****
LOW ELECTROD AMP
*****ERROR*****
MIX MOTOR OVERLD
*****ERROR*****
MaC MOTOR OVERLD
*****ERROR*****
ELECTROD OVERLD
*****ERROR*****
POS FUSE BLOWN
Electrode amps were lower than 7 amps, check salt, clean electrode
with acid treatment, check all connections.
Mixer motor amps were high, Check for foreign material in mixer
chamber, seal leaks, motor shorts
Macerator motor amps were high, Check for foreign material in
macerator chamber, seal leaks, and motor shorts
Electrode amps were higher than 28 amps during fresh water
operation, check for excessive salt, shorted electrode, wiring.
Positive/Negative fuse on I/O connection board is blown due to
some external short, check toilet solenoid type, wiring to solenoid.
Solenoid (relay) to toilet must be isolated coil type or Raritan
solenoid.
*****ERROR*****
NEG FUSE BLOWN
