SPECIFICATIONS
U.S.C.G. Type I MSD Certification #159.015/0107/1
Maximum Roll/Pitch Angle: 30° Capacity: 575 Gallons Per Day
Maximum Temperature Exposure: 120° F (49° C)
Maximum Total Flush Volume: 1.5 gallons/flush (5.7 liters/flush)
Maximum cable length for LCD Dispaly: 16' (5M)
Maximum cable length system status panel: 25' (7.6M)
CONVERSIONS
Wire - AWG to mm
2
Feet to Meters
NOTES FOR WIRING:
Recommended Wire and Fuse/Circuit Breaker Size
Electronic trip Overload settings
IMPORTANT:
A salt feed tank is required when operating system with fresh or brackish water. Operating in low salt conditions
without the addition of salt will shorten life expectancy of the electrode plate and will void warranty.
NOTE: When installed, the salt feed system must be at the same level or lower than the treatment tank.
The following are available to purchase:
NOT FOR USE WITH PRESSURIZED FRESH
WATER TOILETS:
Two Gallon (7.6 liters) Salt Feed Tank
(Part #31-3001) - Tank must be filled with a saturated salt
solution which is dispensed via a T-check valve into incoming
water. One system per toilet. For use in slightly brackish water.
If used in fresh water tank will only last for approximately 15
flushes of the toilet.
Four Gallon (15.2 liters) Salt Feed Tank
(Part #31-3002) - Tank must be connected to pressurized fresh
water and filled with solar salt. The saturated salt solution is
dispensed via a T-check into incoming water. One system per
toilet. Requires manual adjustment as water salinity changes.
Four Gallon (15.2 liters) Salt Feed Tank with Pump
(Part #32-3003 12 Volt and #33-3003 24 Volt) The tank
must be connected to pressurized fresh water and filled
with solar salt. The pump is controlled by the control
box. This system can only be used with the electro scan.
One system per electro scan. This is the most accurate
system to use as the amount of saturated salt solution is
controlled by the actual operating conditions of the
electro scan.
Salt Feed System Options
OK FOR USE WITH PRESSURIZED FRESH-
WATER TOILETS:
