MEASURED DATA X1201 / P1201
The measured data apply to the following appliances:
Unit Model Unit Number Mains Voltage Mains Frequency
X1201
112 736 230V 50 - 60 Hz
X1201
240V 50 - 60 Hz
X1201
100V 50 - 60 Hz
X1201
120V 50 - 60 Hz
P1201
170 149 230V 50 – 60 Hz
P1201
170 148 120V 50 – 60 Hz
P1201
170 148 100V 50 – 60 Hz
MEASURED DATA: X1201 / P1201
Printed boards name and corresponding EDP numbers:
Printed boards EDP numbers
100V 120V 230V 240V
81344 81344 81344 81344
84199 84199 84194
Printed board parts 84194 / 84199 Index
Amplifier - PCB 84194/1 / 84199/1
Bus - PCB 84194/2 / 84199/2
Main - PCB 84194/3 / 84199/3
LED - PCB 84194/4 / 84199/4
Testing Conditions – unless differently stated:
- Measuring tolerance: X= ±1.5dB
- Measuring frequency: f = 1kHz
- Stated level values referred to: U = 775mV (0dBu)
- XLR – socket pin-assignment: PIN 1 = GROUND/SHIELD
PIN 2 = + INPUT
PIN 3 = - INPUT
- Source impedance for signal-feed via XLR – socket: R(Q) = 50
- The printed board assembly 84194 / 84199 offers service connectors.
84194/2 / 84199/2
CNS1X
84194/2 / 84199/2
CNS2X
84194/1 / 84199/1
CN10 / CN11
PIN Assignment PIN Assignment PIN Assignment
1 -Vcc 1 LIM Switch CN10
2 BIAS +HOT 2 -15V 1 FLOAT. Voltage
3 BIAS -HOT 3 SYMMETRY 2 GNDA
4 FAN Voltage 4 +15V 3 GNDA
5 +Vcc 5 GNDA CN11
6 BIAS +COLD 6 Speaker A 1 LIM Switch
7 BIAS -COLD 7 Relay/Protect 2 -15V
8 TEMP Heat sink 8 n.c. 3 -15V
