15. Remote Control Connector Pin-Assignment CNRC / CNRC5V
CNRC CNRC CNRC5V
PIN Assignment PIN Assignment PIN Assignment
1 AMPA2 18 n.c. 1 GND-D
2 +5V 19 HTSNKTMP 2 GND-D
3 COLDCUR+ 20 n.c. 3 POWER-ON
4 +5V 21
HOTCUR- (68Ω/⊥)
4 GND-D
5 COLDCUR- 22 n.c. 5 GND-D
6 KA1 23
HOTCUR+ (68Ω/⊥)
6 +5V
7 LIM-OUTA 24 n.c. 7 +5V
8 KA2 25
AMPB2 (68Ω/⊥)
8 LED-STANDBY
9 n.c. 26 GND-D
10 KA3 27 GND-D
11 POWER-ON 28 GND-D
12 KA4 29 GND-D
13 STBYLED 30
AID5 (10Ω/⊥)
14 KA5 31 AID4
15 TIMER 32 AID3
16 n.c. 33 AID2
17 RELAYDRV 34 AID1
16. Amplifier-ID
AID1: 1 MSB
AID2: 1
↓
AID3: 1
↓
AID4: 1
↓
AID5: 0 LSB
Bin: 11110 Hex: 1E
