Xf Two-Way, MB/HF System
Xf Two-Way, MB/HF System
6
Figure 1 — Polar Response
The directional response of the Xf was measured in an anechoic environment at a distance of 6.1 m (20 ft.) using 1/3-octave-filtered pink
noise with a full spherical measurement system. The Klark Teknik DN8000 digital electronic unit was used to provide the necessary
crossover filters, equalization and time delay. The polar response of the loudspeaker system at selected 1/3-octave frequencies is shown.
The selected frequencies are representative of the polar response of the system.
Vertical
Horizontal
5 dB per division
